TT9333-E(7 mm)Thermal Bullet Network Camera
|
 |
| Overview | Specifications |
Downloads |
Benefits
24/7 Monitoring in non-visible environment
Harnessing heat radiation for superior threat detection in challenging environments, this technology effectively penetrates total darkness, bright glare, deep shadows, smoke, and fog. By capturing clear images based on heat signatures, thermal cameras provide constant, reliable surveillance. The system enables security personnel to identify potential threats in conditions where traditional cameras and the human eye falter, ensuring uninterrupted monitoring in visually complex settings.
Enhance security with VCA detection
Elevate your security with our thermal camera’s VCA system, featuring Object Classification that distinguishes between humans and vehicles. This advanced technology accurately detects intrusions, unauthorized crossings, and suspicious loitering while minimizing false alarms triggered by wildlife or environmental factors, significantly enhancing operational efficiency and ensuring rapid response to genuine threats across diverse settings.
Safeguard Assets with Temperature Measurement
Safeguard your critical assets and prevent disasters with our thermal camera’s comprehensive protection suite, featuring precision temperature monitoring with instant alerts, early fire spot detection, and unauthorized smoking identification, empowering you to take immediate action against potential threats in various environments.
Specifications
|
System Information |
|
| Model | TT9333-E (7 mm) |
| CPU | Multimedia SoC (System-on-Chip) |
| Flash | 16GB |
| RAM | 1GB |
|
Camera Features |
|
| Image Sensor | Dual sensor: Uncooled VOx Micro bolometer + 1/2.7″ Progressive CMOS |
| Max. Resolution | Thermal lens: 256×192 (image scale up to 704×576) / Optical lens: 2560×1440 |
| Lens Type | Fixed-focal (Thermal lens) Fixed-focal (optical lens) |
| Focal Length | Thermal lens: f = 7 mm Optical lens: f = 8 mm |
| Aperture | Thermal lens: F1.0 optical lens: F2.0 |
| Iris Type | Fixed Iris |
| Field of View | Thermal lens (7.0mm) 24.0° (Horizontal) 18.0° (Vertical) optical lens (8.0mm) |
| Illuminators | Built-in IR Illuminator up to 50 meters; White light for strobe light warning |
| Pan/Tilt/Zoom Functionalities | ePTZ: 4x digital zoom |
| Storage | MicroSD/SDHC/SDXC card slot (256GB capacity supported) |
| Pixel Size | 12 µm |
| Spectral Range | 8 ~ 14 µm |
| Sensitivity | NETD < 50 mK |
|
Video |
|
| Video Compression | H.265, H.264, MJPEG |
| Maximum Frame Rate | Thermal: 25 fps @ 704×576 25 fps @ 2560×1440 |
| Maximum Streams | 2 simultaneous streams each sensor |
| Main Stream | Thermal: 25 fps @ 704×576 25 fps @ 2560×1440, 2304×1296, 1920×1080, 1280×720 |
| 2nd Stream | Thermal: 25 fps @ 704×576 25 fps @ 352×240, 256×192, 704×576, 640×480 |
| Video Streaming | Adjustable resolution, CBR/VBR, Smart Encode |
| Image Settings |
General settings video title and time stamp overlay, video orientation (flip, mirror, rotation) Thermal settings white balance, image adjustment (brightness, contrast, sharpness) Privacy mask Scheduled profile settings |
|
Audio |
|
| Audio Capability | Two-way audio |
| Audio Compression | G.711, RAW_PCM |
| Audio Interface | Built-in microphone Built-in speaker External microphone input External line output |
|
Network |
|
| Users | Live viewing for up to 10 clients |
| Security | Access list, Password protection, user access log, user account management |
| Protocols | 802.1X, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, NTP, PPPoE, QoS, RTSP/RTP/RTCP, SMTP, TCP/IP, UDP, UPnP |
| Interface | 10BASE-T/100BASE-TX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
| ONVIF | Profile G, S, T supported, specification available at www.onvif.org |
|
AI Analytics |
|
| Compute Capability | SoC with built-in hardware deep learning accelerator (1T) |
| Application | Temperature measurement alarms (difference, threshold, section, rise),
Early Fire Detection (Fire spot detection, Smoking detection, Smoke & flame detection) VCA (Intrusion, Single line crossing, Double line crossing, Loitering, Wrong way, Enter, Leave) Support VCA alarms triggering by person, car, person or car; Support temperature alarms triggering by ignoring person, car, person or car |
| Solution Integration | |
|
Video Motion Detection
|
Smart motion detection |
|
Alarm and Event |
|
| Event Trigger | Motion detection, I/O alarm, Disk alarm, VCA alarm, Temperature alarm |
| Event Action | Event notification via email, FTP, SD card, digital output, audio clip; white light flashing and horn warning |
|
General |
|
| Connectors | RJ-45 cable connector for 10/100 Mbps Network/PoE connection Audio input Audio output DC 12V power input AC 24V power input Digital input *1 Digital output *1 RS-485 |
| LED Indicator | System power and status indicator |
| Power Input | DC 12V, IEEE 802.3af PoE Class 3 |
| Power Consumption | Max. 10W |
| Dimensions | 140 (D) x 117.8 (H) mm |
| Weight | 1040 g |
| Safety Certifications |
EMC |
| Operating Temperature | Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F) |
| Humidity | 90% |
| Warranty | Up to 36 months |
|
System Requirements |
|
| Operating System | Microsoft Windows 10/8/7 Mac 10.12 (Chrome only) |
| Web Browser | Chrome 58.0 or above Internet Explorer 10/11 |
| Other Players | VLC: 1.1.11 or above |
Temperature Measurement |
|
| Temperature Range | -20°C to 150°C (-4°F to 302°F) |
| Measurement rule | Point, line, polygon (Up to 20 rules in total) |
| Temperature alarm | Threshold alarm, Temperature difference alarm, Temperature rise alarm, Section alarm |
| Accuracy * depends on scene/setting | ± 2°C / ±2% |
|
Included Accessories |
|
| Packing Contents | Quick installation guide, alignment sticker, waterproof accessory bag, screw pack |
|
VCA Detection Range |
|
| VCA Detection Distance (Human: 1.8×0.5m) | 65m (213.3ft) |
| VCA Detection Distance (Vehicle: 4×1.5m) | 144m(472.4ft) |
| Temperature Measurement | |
| Object: 0.2×0.2m | 23.3m (76.4 ft) |
| Fire Detection | |
| Object: 1x1m | 417m (1368ft) |
| Object: 0.2×0.2m | 83.3m (273ft) |
| Smoking Detection | 25m (82ft) |
|
Johnson’s Criteria (Thermal image) |
|
| Human 1.8×0.5m | |
| Detection (1.5 pixels) | 291m (954ft) |
| Recognition (6 pixels) | 73m (239ft) |
| Identification (12 pixels) | 36m (118ft) |
| Vehicle 4×1.5m | |
| Detection (1.5 pixels) | 894m (2933ft) |
| Recognition (6 pixels) | 224m (734ft) |
|
Identification (12 pixels)
|
112m (367ft) |
