SD834-EHL5MP Outdoor AI PTZ Camera
|
 |
| Overview | Specifications |
Downloads |
Benefits
Monitor Anywhere, Anytime, Any Device
VORTEX unifies surveillance extensions on one platform, offering seamless consistency with various cameras. Automate tasks for better productivity and efficiency. Enjoy seamless remote management with instant notifications to your mobile, email, sirens, and Webhooks, ensuring simplified IT maintenance.
Peace of Mind with Up to 10-Year Warranty
VORTEX cameras effortlessly connect to the cloud, scaling without extra servers. Enjoy peace of mind with up to 10-year warranties and continuous license subscriptions for significant cost savings per camera.
AI Hub: From Detection to Data-Driven Insights
Specifications
|
System Information |
|
| Model | SD834-EHL |
|
Camera Features |
|
| Image Sensor | 1/2.8″ Progressive CMOS |
| Max. Resolution | SD: 1280×960 HD: 2560×1920 |
| Lens Type | 30x Optical Zoom, Auto Focus |
| Focal Length | f = 4.94 ~ 148.24 mm (30x zoom) |
| Aperture | F1.3 ~ F4.6 |
| Auto-iris | DC-iris |
| Field of View | 54.1° ~ 1.9° (Horizontal) 41.2° ~ 1.4° (Vertical) 65.7° ~ 2.4° (Diagonal) |
| Shutter Time | 1/5 sec. to 1/32,000 sec. |
| WDR Technology | WDR Pro |
| Day/Night | Yes |
| Removable IR-cut Filter | Yes |
| IR Illuminators |
Built-in IR illuminators up to 200 meters with Smart IR, IR LED*8 |
| Minimum Illumination | 0.03 lux @ F1.3 (Color) 0.005 lux @ F1.3 (B/W) 0 lux with IR illumination on |
| Pan Speed | 0.05° ~ 450°/sec |
| Pan Range | 360° endless |
| Tilt Speed | 0.05° ~ 450° /sec |
| Tilt Range | -20° ~ +90° |
| Preset Location | 256 preset locations / 128 presets per tour |
| Storage | MicroSD/SDHC/SDXC card slot (Built-in 256GB industrial SDCard) |
|
Video |
|
| Video stream settings | HD Video 2560 x 1920@15fps 1.2Mbps upload SD Video 1280 x 960@15fps 300Kbps upload |
| Audio | |
| Audio Capability | Two-way Audio (full duplex) (xPro License required to enable speaker talk-down feature) |
| Audio Interface | External line input External line output |
|
Network |
|
| Users | Up to 6 clients *Live viewing for 6 clients *live viewing up to 4 clients and playback 2 clients |
| Security |
Secure boot, Signed firmware, HTTPS/TLS encryption, Video encryption |
| Protocols | ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, NTP, RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP, WebRTC |
| Interface | 10BASE-T/100BASE-TX Ethernet (RJ-45) *It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
|
General |
|
| Connectors | RJ-45 cable connector for 10/100 Mbps Network/PoE connection Audio line input * Audio line output * DC 48V power input AC 24V power input Digital input *2 * Digital output *1 * RS-485 *1 * * Requires AO-008 cable |
| LED Indicator | System power and status indicator |
| Power Input | AC 24V, DC48V, IEEE 802.3bt Class 6 PoE (Simultaneous Power Redundancy Supported) |
| Power Consumption | PoE Max: 51W/26W (IR on/off) DC 48V Max: 51W/26W (IR on/off) AC 24V Max: 51W/26W (IR on/off) IR on: 51W/45W Heater and fan on/off IR off: 26/20W Heater and fan on/off |
| Dimensions |
256 (D) x 336 (H) mm |
| Weight | 7.1 kg |
| Safety Certifications |
EMC |
| Operating Temperature | Starting Temperature: -40°C ~ 55°C (-40°F ~ 131°F) Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F) (IR on) |
| Humidity | 98% RH (non-condensing) |
| Warranty |
Up to 60 months (Depends on license type) |
|
Included Accessories |
|
| Packing Contents |
Wall mount bracket, Quick installation guide, Screws and anchors, T10 and T25 L-wrench, Waterproof round cap, screw pack, Ground wire, Terminal blocks (for DI/DO audio, AC/DC/GND wires, RS485) |
|
VORTEX AI Analytics |
|
| Application | Intrusion detection Line crossing detection Loitering detection Unattended object detection Missing object detection |
| Audio detection | Yes |
| Camera tampering detection | Yes |
| AI Hub (xPro license required) | Attribute search Scene search Re-search Profile search LPR search Think search Event insight Facial recognition |
